Gantry 450C 细密数控电火花机床接纳黄金支解比例设计的外观造型，整机色彩搭配匀称、协调、豪华、大气，
伸缩式的主轴防护设计确保了机床操作的清静性。
|
机床/Machine tool |
|
|
机床重量/Weight of machine tool |
4500kg |
|
电柜重量/Weight of electric cabinet |
640kg |
|
输入功率/Input power |
16kVA |
|
熔断�；さ缌�/Fuse protection current |
32A |
|
主电压/频率/Main voltage / frequency |
400/50 V/Hz |
|
事情油箱/Working oil tank |
|
|
类型/Type |
整体升降/Integral lifting |
|
事情油箱内部尺寸（长xk宽x高)/Working oil tank inner size (long x wide x high) |
800x550x340mm |
|
最大液面高度可编程/自动/Maximum height of the liquid level can be programmed / automatic |
300mm |
|
事情头部/Working head |
|
|
最大电极重量/Maximum electrode weight |
100kg |
|
事情台到卡盘基准距离 最小/最大/Table to chuck the reference distance minimum / maximum |
150/450mm |
|
事情台/workbench |
|
|
事情台尺寸（长x宽）/Table size (length x width) |
700x520mm |
|
最大工件重量/Maximum weight of workpiece |
1000kg |
|
行程/Trip |
|
|
X/Y/Z在加工槽内的行程/X/Y/Z stroke in the processing slot |
450x350x300mm |
|
Y（电极交流和装卸时行程）/Y (electrode exchange and loading and unloading trip) |
350mm |
|
控制系统/Control system |
|
|
PC-NC对话/PC-NC dialogue |
2x32bit |
|
驱动类型/Drive type |
数字交流伺服电机/Digital AC servo motor |
|
XYZ轴移动速率（标准设置）/XYZ axis movement speed (standard configuration) |
最大5000mm/min/Max 5000mm/min |
|
集油槽/Oil sump |
|
|
过滤单位/Filter unit |
筒（内置）/Cylinder (built in) |
|
过滤面积/Filtration area |
16㎡ |
|
集油箱总容量/Total tank capacity |
370ltr |
|
电源 |
|
|
类型/Type |
脉冲形状自顺应控制/Adaptive pulse shape control |
|
最大事情电流/Maximum operating current |
60A |
|
特殊特点/Additional features |
|
|
润滑系统/lubrication system |
标准设置/Standard configuration |
|
冷却系统/Cooling system |
标准设置/Standard configuration |
|
自动灭火装置/Automatic fire extinguishing device |
标准设置/Standard configuration |
